| Uimhir Pháirt | TM040YDH51 |
| Branda | TIANMA |
| Méid | 4.0 |
| Iarratas | Mobile Phone |
| Rún | 480×800 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S1P |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM040YDH51 |
| méid scáileáin | 4.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 480(RGB)×800 (WVGA) 235PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 51.84 × 86.4 (H×V) |
| imlíne (mm) | 57.24 × 98.3 × 2.3 (H×V×D) |
| limistéar bezel (mm) | 52.84 × 87.4 (H×V) |
| cóireáil | Clear |
| luminance | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 600 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/70/60 (Typ.)(CR≥10) |
| freagra | 20 (Typ.)(Tr+Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 16.7M 60% NTSC |
| cúlsolas | 7S1P WLED , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Mobile Phone |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
