| Uimhir Pháirt | TM028HDZG59 |
| Branda | TIANMA |
| Méid | 2.8 |
| Iarratas | Mobile Phone |
| Rún | 240×320 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 400:1 |
| Dathanna | 65K/262K |
| Cúlsolas | WLED |
| Comhéadan | 16-bit |
| branda | TIANMA |
| méid trasnánach | 2.8 inch |
| formáid picteilín | 240(RGB)×320 [QVGA] 141PPI |
| limistéar gníomhach | 43.2(H)×57.6(V) mm |
| luminance | 300 cd/m² (Typ.) |
| treo amharc | - |
| uillinn féachana | 70/70/70/58 (Typ.)(CR≥10) |
| dath tacaíochta | 65K/262K 63% NTSC |
| meáchan | TBD |
| ráta fhráma | - |
| cineál comhéadan | 16-bit 8080 parallel , 37 pins FPC |
| soláthar leictreachas | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Mionsamhail | TM028HDZG59 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 50(H)×69.2(V) mm |
| cóimheas codarsnachta | 400:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED [1S4P] , W/O Driver |
| deartha le haghaidh | Mobile Phone |
| painéal tadhaill | Without |
