| Uimhir Pháirt | TM028HDZ58 |
| Branda | TIANMA |
| Méid | 2.8 |
| Iarratas | Mobile Phone |
| Rún | 240×320 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 65K/262K |
| Cúlsolas | 1S4P |
| Comhéadan | Parallel |
| monaróir | TIANMA |
| ainm samhail | TM028HDZ58 |
| méid scáileáin | 2.8 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 240(RGB)×320 (QVGA) 141PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 43.2 × 57.6 (H×V) |
| imlíne (mm) | - |
| luminance | - |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 60/60/60/50 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 65K/262K 55% NTSC |
| cúlsolas | 1S4P WLED , No Driver |
| mais | - |
| a úsáidtear le haghaidh | Mobile Phone |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) + SPI |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
