| Uimhir Pháirt | TM026HDH02 |
| Branda | TIANMA |
| Méid | 2.6 |
| Iarratas | Mobile Phone |
| Rún | 240×320 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 65K/262K |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM026HDH02 |
| méid scáileáin | 2.6 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 240(RGB)×320 (QVGA) 156PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 38.88 × 51.84 (H×V) |
| imlíne (mm) | - |
| luminance | 240 cd/m² (Typ.) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/70/60 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 65K/262K 60% NTSC |
| cúlsolas | WLED , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Mobile Phone |
| ráta athnuachana | - |
| scáileán tadhaill | Without |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C |
