| Uimhir Pháirt | TM024HDHG04 |
| Branda | TIANMA |
| Méid | 2.4 |
| Iarratas | Handheld & PDA |
| Rún | 240×320 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | - |
| Cúlsolas | WLED |
| Comhéadan | CPU |
| branda painéil | TIANMA |
| múnla painéil | TM024HDHG04 |
| méid an phainéil | 2.4" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 240(RGB)×320, QVGA, 166PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 36.72(W)×48.96(H) mm |
| oscailt bezel | - |
| gile | - |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| uillinn féachana | 70/70/70/60 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | - |
| am freagartha | 20 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | |
| cineál lampa | WLED |
| minicíocht | - |
| scáileán tadhaill | Without |
| meáchan painéal | - |
| iarratas | Handheld & PDA |
| comhéadan comhartha | CPU FPC |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| DMC-16117A | Kyocera | 2.4 | 16×1 |
| LS024J3LX01 | SHARP | 2.4 | 320×480 |
| LTM024P339 | TOSHIBA | 2.4 | 240×320 |
| RGS24128064YW005 | RiTdisplay | 2.4 | 128×64 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
