| Uimhir Pháirt | TL055BDXP03 |
| Branda | TIANMA |
| Méid | 5.5 |
| Iarratas | Mobile Phone |
| Rún | 1440×2560 |
| Comhdhéanamh | LCM , LTPS TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 5S3P |
| Comhéadan | MIPI |
| monaróir | TIANMA |
| méid scáileáin | 5.5 inch |
| uimhir picteilín | 1440(RGB)×2560 (Quad-HD) 537PPI |
| limistéar gníomhach(mm) | 68.04 × 120.96 (H×V) |
| luminance | - |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 70% NTSC |
| mais | TBD |
| ráta athnuachana | 70Hz |
| cineál comhartha | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| soláthar voltais | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| uas. rátálacha | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| ainm samhail | TL055BDXP03 |
| cineál scáileáin | LCM , LTPS TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| freagra | 8 (Typ.)(Tr+Td) ms |
| modh oibre | SFT, Normally Black, Transmissive |
| cúlsolas | 5S3P WLED |
| a úsáidtear le haghaidh | Mobile Phone |
| scáileán tadhaill | Without |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055W1GC01 | SHARP | 5.5 | 1024×600 |
| LS055T1SX01 | SHARP | 5.5 | 1080×1920 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| UG-5664ASYGF01 | WiseChip | 5.5 | 256×64 |
