| Uimhir Pháirt | TCG085WVLCF-G00 |
| Branda | Kyocera |
| Méid | 8.5 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| monaróir | Kyocera |
| ainm samhail | TCG085WVLCF-G00 |
| méid scáileáin | 8.5 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 109PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 184.8 × 110.88 (H×V) |
| imlíne (mm) | 210 × 134 × 11.1 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare |
| luminance | 320 cd/m² (Typ.) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 60/60/60/45 (Typ.)(CR≥10) |
| freagra | 15/35 (Typ.)(Tr/Td) ms |
| radharc maith ag | - |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K 49% NTSC |
| cúlsolas | WLED , 50K hours , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | 4-wire Resistive Touch, G/G |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
