| Uimhir Pháirt | T390XVN02.0 CELL |
| Branda | AUO |
| Méid | 39 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | CELL , a-Si TFT-LC |
| Gile | |
| CR | 5000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | AUO |
| ainm samhail | T390XVN02.0 CELL |
| méid scáileáin | 39 inch |
| cineál scáileáin | CELL , a-Si TFT-LCD |
| uimhir picteilín | 1366(RGB)×768 (WXGA) 40PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 853.409 × 479.808 (H×V) |
| imlíne (mm) | 868.72 × 492.83 × 1.4 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare (Haze 2%), Hard coating (3H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 5000 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 8 (Typ.)(G to G) ms |
| radharc maith ag | Symmetry |
| modh oibre | AMVA, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | 8% (Typ.)(with Polarizer) |
| doimhneacht dath | 16.7M 68% NTSC |
| cúlsolas | No B/L |
| mais | 1.30Kgs (Typ.) |
| a úsáidtear le haghaidh | TV Sets |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Ic liosta tiománaí | Built-in COF 4 source chips |
| cineál comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
