| Uimhir Pháirt | STCG057QVLAM-G02-S |
| Branda | Kyocera |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 320×240 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | Kyocera |
| Mionsamhail | STCG057QVLAM-G02-S |
| méid trasnánach | 5.7 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 320(RGB)×240 [QVGA] 70PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 115.2(H)×86.4(V) mm |
| imlíne dim. | 144(H)×104.8(V) ×13.5(D) mm |
| limistéar bezel | 118.4(H)×89.0(V) mm |
| cóireáil | Glare (Haze 0%) |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 10/25 (Typ.)(Tr/Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥5) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 60% NTSC |
| foinse solais | WLED , 40K hours , W/O Driver |
| meáchan | 158g (Typ.) |
| deartha le haghaidh | Industrial |
| ráta fhráma | - |
| painéal tadhaill | Without |
| cineál comhéadan | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
