| Uimhir Pháirt | S062WV04 |
| Branda | CDTECH |
| Méid | 6.2 |
| Iarratas | Industrial Automotiv |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S9P |
| Comhéadan | |
| monaróir | CDTECH |
| méid scáileáin | 6.2 inch |
| uimhir picteilín | 800(RGB)×480 (WVGA) 150PPI |
| limistéar gníomhach(mm) | 137.52 × 77.232 (H×V) |
| limistéar bezel (mm) | 140.7 × 80.4 (H×V) |
| luminance | 600 (Typ.)(cd/m²) |
| uillinn féachana | 65/65/55/65 (Typ.)(CR≥10) |
| radharc maith ag | - |
| doimhneacht dath | 16.7M |
| mais | TBD |
| ráta athnuachana | 60Hz |
| ainm samhail | S062WV04 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 155.2 × 88.2 × 3.7 (H×V×D) |
| cóireáil | - |
| cóimheas codarsnachta | 600 : 1 (Typ.) (TM) |
| modh oibre | TN, Normally White, Transmissive |
| freagra | 30/30 (Typ.)(Tr/Td) ms |
| cúlsolas | 3S9P WLED , 25K hours , No Driver |
| a úsáidtear le haghaidh | Industrial Automotive Display |
| scáileán tadhaill | Without |
| AT062TN12 | Innolux | 6.2 | |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| PW062XS6 | E Ink | 6.2 | 480×234 |
| PW062XU7 | E Ink | 6.2 | 480×234 |
| PW062XU8 | E Ink | 6.2 | 480×234 |
| TM062RDH03 | Tianma | 6.2 | 800×480 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
| TX16D11VM2CCA | KOE | 6.2 | 640×240 |
| TX16D18VM2CAB | KOE | 6.2 | 800×300 |
