| Uimhir Pháirt | QD14XL20 Rev.03 |
| Branda | QDI |
| Méid | 14.1 |
| Iarratas | NBPC |
| Rún | 1024×768 |
| Comhdhéanamh | LCM |
| Gile | 185 |
| CR | 300:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | QDI |
| múnla painéil | QD14XL20 Rev.03 1 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 14.1 inch |
| taifeach | 1024(RGB)×768 , XGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 285.696×214.272 mm |
| imlíne | 299×240.6×5.5 mm |
| stíl cruth | Wedge (PCBA Bent, Depth ≥5.2mm) |
| dromchla | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| gile | 185 cd/m² (Typ.) |
| cóimheas codarsnachta | 300:1 (Min.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193142% |
| am freagartha | 10/15 (Typ.)(Tr/Td) |
| uillinn féachana | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLEmbedded (Inverter) |
| comhéadan comhartha | LVDS (1 ch, 6-bit), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
