| Uimhir Pháirt | PT236AT01-1 |
| Branda | HKC |
| Méid | 23.6 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | CELL , a-Si TFT-LC |
| Gile | |
| CR | 3000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | |
| monaróir | HKC |
| méid scáileáin | 23.6 inch |
| uimhir picteilín | 1366(RGB)×768 (WXGA) 66PPI |
| limistéar gníomhach(mm) | 521.471 × 293.184 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 0 (cd/m²) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| tiús gloine | 0.50+0.50 mm |
| doimhneacht dath | 16.7M 68% NTSC |
| mais | 500g (Typ.) |
| ráta athnuachana | 60Hz |
| ainm samhail | PT236AT01-1 |
| cineál scáileáin | CELL , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 535.471 × 306.404 × 1.37 (H×V×D) |
| cóireáil | Antiglare (Haze 3%), Hard coating (3H) |
| cóimheas codarsnachta | 3000 : 1 (Typ.) (TM) |
| modh oibre | FSA, Normally Black, Transmissive |
| freagra | 9.5 (Typ.)(G to G) ms |
| transmissivity | 6.0% (Typ.)(with Polarizer) |
| cúlsolas | No B/L |
| a úsáidtear le haghaidh | TV Sets |
| scáileán tadhaill | Without |
| HR236WU1-300 | BOE | 23.6 | 1920×1080 |
| LQ235D1LW03 | SHARP | 23.6 | 1920×1080 |
| M236H3-LA2 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L5B | Innolux | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| P236MWF1 R0 | IVO | 23.6 | 1920×1080 |
| V236BJ1-LE1 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V236H1-LE4 | Innolux | 23.6 | 1920×1080 |
