| Uimhir Pháirt | P0650VGF1MA10 |
| Branda | TIANMA |
| Méid | 6.5 |
| Iarratas | Industrial Outdoor H |
| Rún | 640×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 6S2P |
| Comhéadan | LVDS |
| branda painéil | TIANMA |
| múnla painéil | P0650VGF1MA10 |
| méid an phainéil | 6.5" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 640(RGB)×480, VGA, 122PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 132.48(W)×99.36(H) mm |
| oscailt bezel | 135.48(W)×102.36(H) mm |
| méid imlíne | 153(W)×118(H) ×11.2(D) mm |
| dromchla | Antiglare |
| gile | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | SFT, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 262K/16.7M 70% NTSC |
| cineál lampa | 6S2P WLED , 70K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | TBD |
| iarratas | Industrial Outdoor High Brightness Automotive Display |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| DJ065NA-01C | Innolux | 6.5 | |
| L5F30818P03 | SONY | 6.5 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LB065WQ3-TD02 | LG Display | 6.5 | 400×240 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ065Y5DG01 | SHARP | 6.5 | 800×480 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
