| Uimhir Pháirt | NV156FHM-T05 |
| Branda | BOE |
| Méid | 15.6 |
| Iarratas | Laptop |
| Rún | 1920×1080 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K |
| Cúlsolas | 10S4P |
| Comhéadan | eDP |
| monaróir | BOE |
| ainm samhail | NV156FHM-T05 (BOE07F2) |
| méid scáileáin | 15.6 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×1080 (FHD) 141PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 344.16 × 193.59 (H×V) |
| imlíne (mm) | 350.66 × 205.69 × 5.4 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 220 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | ADS, Normally Black, Transmissive |
| doimhneacht dath | 262K 45% NTSC |
| cúlsolas | 10S4P WLED , 15K hours , With LED Driver |
| cruth imlíne | Slim (PCBA Bent, T≤3.0mm) |
| a úsáidtear le haghaidh | Laptop |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | On-Cell Touch |
| cineál comhartha | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , Connector 40 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B156XTN04.1 | AUO | 15.6 | 1366×768 |
| B156XW02 V3 | AUO | 15.6 | 1366×768 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LP156WH1-TLA1 | LG Display | 15.6 | 1366×768 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| M156B1-L01 | Innolux | 15.6 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| NV156FHM-N41 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N42 | BOE | 15.6 | 1920×1080 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
