| Uimhir Pháirt | NV101WUM-N52 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | MIPI |
| monaróir | BOE |
| méid scáileáin | 10.1 inch |
| uimhir picteilín | 1200(RGB)×1920 (WUXGA) 225PPI |
| limistéar gníomhach(mm) | 135.36 × 216.576 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 68% NTSC |
| mais | 132g (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | MIPI (4 data lanes) , 42 pins Connector |
| soláthar voltais | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | NV101WUM-N52 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| freagra | 35 (Max.)(Tr+Td) ms |
| modh oibre | ADS, Normally Black, Transmissive |
| cúlsolas | WLED , 15K hours , No Driver |
| a úsáidtear le haghaidh | Pad & Tablet |
| scáileán tadhaill | Without |
