| Uimhir Pháirt | NL8048BC21-03F |
| Branda | NLT |
| Méid | 8.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | NLT |
| méid trasnánach | 8.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 116PPI |
| limistéar gníomhach | 174(H)×104.4(V) mm |
| limistéar bezel | - |
| luminance | 1000 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| dath tacaíochta | 262K/16.7M 72% NTSC |
| meáchan | 225g |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| Mionsamhail | NL8048BC21-03F |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 192(H)×122(V) mm |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| am freagartha | 20 (Typ.)(Tr+Td) |
| modh oibriúcháin | SFT, Normally Black, Transmissive |
| foinse solais | WLED |
| deartha le haghaidh | Industrial Outdoor High Brightness |
| painéal tadhaill | Without |
