| Uimhir Pháirt | NL6448AC33-A1D |
| Branda | NLT |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | NLT |
| ainm samhail | NL6448AC33-A1D |
| méid scáileáin | 10.4 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 640(RGB)×480 (VGA) 76PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 211.2 × 158.4 (H×V) |
| imlíne (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare |
| luminance | 370 cd/m² (Typ.) |
| cóimheas codarsnachta | 900 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 18 (Typ.)(Tr+Td) ms |
| radharc maith ag | - |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K |
| cúlsolas | WLED , 100K hours , With LED Driver |
| mais | 380g (Max.) |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
