| Uimhir Pháirt | NL6448AC33-A0D |
| Branda | NLT |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 640×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | CMOS |
| branda painéil | NLT |
| méid an phainéil | 10.4" |
| taifeach | 640(RGB)×480, VGA, 76PPI |
| limistéar taispeána | 211.2(W)×158.4(H) mm |
| méid imlíne | 246.5(W)×179.4(H) ×10(D) mm |
| gile | 500 cd/m² (Typ.) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc is fearr ar | - |
| dathanna a thaispeáint | 262K 40% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 390/435g (Typ./Max.) |
| comhéadan comhartha | CMOS (1 ch, 6-bit) , 31 pins Connector |
| voltas ionchuir | 3.3/5.0V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| múnla painéil | NL6448AC33-A0D |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 3/15 (Typ.)(Tr/Td) |
| cineál lampa | WLED , 100K hours , With LED Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-18A | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
