| Uimhir Pháirt | NL12880BC20-25F |
| Branda | NLT |
| Méid | 12.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×800 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 3 |
| Comhéadan | LVDS |
| monaróir | NLT |
| ainm samhail | NL12880BC20-25F |
| méid scáileáin | 12.1 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×800 (WXGA) 124PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 261.12 × 163.2 (H×V) |
| imlíne (mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| limistéar bezel (mm) | 266.1 × 168.2 (H×V) |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 1600 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 15 (Typ.)(Tr+Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K/16.7M 50% NTSC |
| cúlsolas | 3 strings WLED , 60K hours , No Driver |
| mais | 470g (Typ.) |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
