| Uimhir Pháirt | NL10276BC30-39 |
| Branda | NLT |
| Méid | 15.0 |
| Iarratas | IA |
| Rún | 1024×768 |
| Comhdhéanamh | LCM |
| Gile | 270 |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | NEC |
| múnla painéil | NL10276BC30-39 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 15.0 inch |
| taifeach | 1024(RGB)×768 , XGA |
| mód taispeána | UA-SFT, Normally Black, Transmissive |
| limistéar gníomhach | 304.128×228.096 mm |
| imlíne | 326.5×253.5×12.2 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 270 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit), CIE193172% |
| am freagartha | 14/11 (Typ.)(Tr/Td) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 6 stringsWLEDWithout Driver |
| comhéadan comhartha | LVDS (1 ch, 8-bit), 20 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
