| Uimhir Pháirt | NE156FHM-NZ1 |
| Branda | BOE |
| Méid | 15.6 |
| Iarratas | Laptop Gaming |
| Rún | 1920×1080 |
| Comhdhéanamh | LCM , Oxide TFT-LC |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 9S6P |
| Comhéadan | eDP |
| monaróir | BOE |
| méid scáileáin | 15.6 inch |
| uimhir picteilín | 1920(RGB)×1080 (FHD) 141PPI |
| limistéar gníomhach(mm) | 344.16 × 193.59 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 300 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 100% sRGB |
| cruth imlíne | Slim (PCBA Flat, T≤3.2mm) |
| ráta athnuachana | 240Hz |
| cineál comhartha | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | NE156FHM-NZ1 (BOE0865) |
| cineál scáileáin | LCM , Oxide TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 350.66 × 216.05 × 2.6 (H×V×D) |
| cóireáil | Antiglare (Haze 25%) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| freagra | 8 (Typ.)(Tr+Td); 4 (Typ.)(G to G) ms |
| modh oibre | HADS, Normally Black, Transmissive |
| cúlsolas | 9S6P WLED , 15K hours , With LED Driver |
| a úsáidtear le haghaidh | Laptop Gaming |
| scáileán tadhaill | Without |
| B156XTK01.0 | AUO | 15.6 | 1366×768 |
| B156XTN03.1 | AUO | 15.6 | 1366×768 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP156WF3-SLB1 | LG Display | 15.6 | 1920×1080 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LQ156M1LG21 | SHARP | 15.6 | 1920×1080 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT09-B02 | Samsung | 15.6 | 1366×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L04 | Innolux | 15.6 | 1366×768 |
