| Uimhir Pháirt | NE135FBM-N41 |
| Branda | BOE |
| Méid | 13.5 |
| Iarratas | Laptop |
| Rún | 2256×1504 |
| Comhdhéanamh | Oxide TFT-LCD, LCM |
| Gile | |
| CR | 1500:1 |
| Dathanna | 16.7M |
| Cúlsolas | 9S6P |
| Comhéadan | eDP |
| branda painéil | BOE |
| múnla painéil | NE135FBM-N41 (BOE08BC BOE095F) |
| méid an phainéil | 13.5" |
| cineál painéil | Oxide TFT-LCD, LCM |
| taifeach | 2256(RGB)×1504, 201PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 284.933(W)×189.955(H) mm |
| oscailt bezel | - |
| méid imlíne | 289.993(W)×212.28(H) ×2.1(D) mm |
| dromchla | Hard coating (2H) |
| gile | 415 cd/m² (Typ.) |
| cóimheas codarsnachta | 1500:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | FFS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 100% sRGB |
| cineál lampa | 9S6P WLED , 15K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| stíl cruth | Slim (PCBA Flat, T≤3.2mm) |
| iarratas | Laptop |
| comhéadan comhartha | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
