| Uimhir Pháirt | N156HCA-EAB |
| Branda | Innolux |
| Méid | 15.6 |
| Iarratas | Laptop |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda | Innolux |
| méid trasnánach | 15.6 inch |
| formáid picteilín | 1920(RGB)×1080 [FHD] 141PPI |
| limistéar gníomhach | 344.16(H)×193.59(V) mm |
| limistéar bezel | - |
| luminance | 250 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 45% NTSC |
| stíl fhoirm | Slim (PCBA Flat, T≤3.2mm) |
| ráta fhráma | 60Hz |
| cineál comhéadan | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Mionsamhail | N156HCA-EAB (CMN15E7) |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 350.66(H)×216.25(V) ×3.2(D) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| am freagartha | 14/11 (Typ.)(Tr/Td) |
| modh oibriúcháin | AAS, Normally Black, Transmissive |
| foinse solais | WLED , 15K hours , With LED Driver |
| deartha le haghaidh | Laptop |
| painéal tadhaill | Without |
