Uimhir Pháirt | N133BGE-LB1 |
Branda | Innolux |
Méid | 13.3 |
Iarratas | NBPC |
Rún | 1366×768 |
Comhdhéanamh | LCM |
Gile | 200 |
CR | 500:1 |
Dathanna | 262K |
Cúlsolas | WLED |
Comhéadan | LVDS |
branda painéil | CHIMEI INNOLUX |
múnla painéil | N133BGE-LB1 |
cineál painéil | a-Si TFT-LCD , LCM |
méid an phainéil | 13.3 inch |
taifeach | 1366(RGB)×768 , WXGA |
mód taispeána | TN, Normally White, Transmissive |
limistéar gníomhach | 293.42×164.97 mm |
imlíne | 318.3×188.7×3.05 mm |
stíl cruth | Slim (PCBA Flat, Depth ≤3.2mm) |
dromchla | Glare (Haze 0%), Hard coating (3H) |
gile | 200 cd/m² (Typ.) |
cóimheas codarsnachta | 500:1 (Typ.) |
dathanna a thaispeáint | 262K (6-bit), CIE193145% |
am freagartha | 8/8 (Typ.)(Tr/Td) |
uillinn féachana | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
minicíocht | 60Hz |
cineál lampa | WLEDEmbedded (LED Driver) |
comhéadan comhartha | LVDS (1 ch, 6-bit), 40 pins |
voltas ionchuir | 3.3V (Typ.) |
iarratas | NBPC |
