| Uimhir Pháirt | MV230FHB-N40 |
| Branda | BOE |
| Méid | 23.0 |
| Iarratas | Desktop Monitor |
| Rún | 1920×1080 |
| Comhdhéanamh | CELL, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | BOE |
| ainm samhail | MV230FHB-N40 |
| méid scáileáin | 23.0 inch |
| cineál scáileáin | CELL, a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×1080 (FHD) 95PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 509.184 × 286.416 (H×V) |
| imlíne (mm) | 517 × 298.096 × 1.32 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 1000 : 1 (Min.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 14 (Typ.)(G to G) ms |
| radharc maith ag | Symmetry |
| modh oibre | ADS, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | 5.3% (Typ.)(with Polarizer) |
| doimhneacht dath | 16.7M NTSC |
| cúlsolas | No B/L |
| mais | 484g (Typ.) |
| a úsáidtear le haghaidh | Desktop Monitor |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Ic liosta tiománaí | Built-in COF 6 source chips |
| cineál comhartha | LVDS (2 ch, 8-bit) , Connector 30 pins |
| soláthar voltais | 5.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
