| Uimhir Pháirt | MNF601BA1-1 |
| Branda | CSOT |
| Méid | 15.6 |
| Iarratas | Laptop |
| Rún | 1920×1080 |
| Comhdhéanamh | LTPS TFT-LCD , LCM |
| Gile | |
| CR | 1500:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda | CSOT |
| méid trasnánach | 15.6 inch |
| formáid picteilín | 1920(RGB)×1080 [FHD] 141PPI |
| limistéar gníomhach | 344.16(H)×193.59(V) mm |
| limistéar bezel | - |
| luminance | 400 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 98% sRGB |
| stíl fhoirm | Slim (PCBA Bent, T≤3.0mm) |
| ráta fhráma | 60Hz |
| cineál comhéadan | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Mionsamhail | MNF601BA1-1 (CSO1506) |
| cineál | LTPS TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 319.16(H)×204.49(V) ×2.6(D) mm |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 1500:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | FFS, Normally Black, Transmissive |
| foinse solais | WLED [9S6P] , 15K hours , With LED Driver |
| deartha le haghaidh | Laptop |
| painéal tadhaill | Without |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| BT156GW02 V.0 | Innolux | 15.6 | 1366×768 |
| LP156WF3-SLB1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLD1 | LG Display | 15.6 | 1366×768 |
| LQ156T3LW02 | SHARP | 15.6 | 1366×768 |
| LTN156AT01-D02 | Samsung | 15.6 | 1366×768 |
| M156MWR1 R0 | IVO | 15.6 | 1366×768 |
| N156B6-L04 | Innolux | 15.6 | 1366×768 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| NT156WHM-N42 | BOE | 15.6 | 1366×768 |
