| Uimhir Pháirt | M116NWR1 R0 |
| Branda | IVO |
| Méid | 11.6 |
| Iarratas | NBPC |
| Rún | 1366×768 |
| Comhdhéanamh | LCM |
| Gile | 200 |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | IVO |
| múnla painéil | M116NWR1 R0 3 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 11.6 inch |
| taifeach | 1366(RGB)×768 , WXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 256.125×144 mm |
| imlíne | 278×167×3.6 mm |
| stíl cruth | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| dromchla | Glare (Haze 0%) |
| gile | 200 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193145% |
| am freagartha | 10 (Typ.)(Tr+Td) |
| uillinn féachana | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | LVDS (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LTN116AT01-801 | Samsung | 11.6 | 1366×768 |
| LTN116AT02-D01 | Samsung | 11.6 | 1366×768 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| M116NWR4 R0 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| LP104V2-W | LG Display | 10.4 | 640×480 |
| LP154WE2-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP156WHB-TLA1 | LG Display | 15.6 | 1366×768 |
| LP171WP4-TLN2 | LG Display | 17.1 | 1440×900 |
| LP171WP6-TL04 | LG Display | 17.1 | 1440×900 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN154X3-L01 | Samsung | 15.4 | 1280×800 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| N154I2-L05 | Innolux | 15.4 | 1280×800 |
