| Uimhir Pháirt | M102AWF2 R1 |
| Branda | IVO |
| Méid | 10.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | IVO |
| Mionsamhail | M102AWF2 R1 |
| méid trasnánach | 10.3 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1920(RGB)×720 200PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 243.65(H)×91.37(V) mm |
| imlíne dim. | 262.04(H)×110.3(V) ×12.2(D) mm |
| limistéar bezel | 245.65(H)×93.66(V) mm |
| cóireáil | Hard coating (3H) |
| luminance | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 20 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 72% NTSC |
| foinse solais | WLED [8S3P] , 10K hours , W/O Driver |
| meáchan | 380g (Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (2 ch, 8-bit) , 50 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
