| Uimhir Pháirt | M090AWP4 R1 |
| Branda | IVO |
| Méid | 9.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| monaróir | IVO |
| méid scáileáin | 9.0 inch |
| uimhir picteilín | 800(RGB)×480 (WVGA) 104PPI |
| limistéar gníomhach(mm) | 198 × 112.08 (H×V) |
| limistéar bezel (mm) | 200.2 × 114.28 (H×V) |
| luminance | 750 cd/m² (Typ.) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| radharc maith ag | 6 o'clock |
| doimhneacht dath | 262K 70% NTSC |
| mais | - |
| ráta athnuachana | 60Hz |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| uas. rátálacha | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
| ainm samhail | M090AWP4 R1 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 210.82 × 126.96 × 6.4 (H×V×D) |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 700 : 1 (Typ.) (TM) |
| freagra | 12 (Typ.)(Tr+Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | WLED , No Driver |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| scáileán tadhaill | Without |
