| Uimhir Pháirt | M090AWA5 R0 |
| Branda | IVO |
| Méid | 9.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 1280×720 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S4P |
| Comhéadan | |
| monaróir | IVO |
| ainm samhail | M090AWA5 R0 |
| méid scáileáin | 9.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×720 (WXGA) 163PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 198.72 × 111.78 (H×V) |
| imlíne (mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| limistéar bezel (mm) | 201.72 × 114.78 (H×V) |
| cóireáil | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| luminance | 880 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 70% NTSC |
| cúlsolas | 7S4P WLED , 15K hours , No Driver |
| mais | 335g (Max.) |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
