| Uimhir Pháirt | LTM230HT09 |
| Branda | Samsung |
| Méid | 23.0 |
| Iarratas | DMPC |
| Rún | 1920×1080 |
| Comhdhéanamh | LCM |
| Gile | 250 |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | SAMSUNG |
| múnla painéil | LTM230HT09 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 23.0 inch |
| taifeach | 1920(RGB)×1080 , FHD |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 509.76×286.74 mm |
| imlíne | 534×311.7×10.7 mm |
| dromchla | Antiglare (Haze 25%), Hard coating (3H) |
| gile | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (6-bit + Hi-FRC), CIE193172% |
| am freagartha | 5 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 13S3PWLEDWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 30 pins |
| voltas ionchuir | 5.0V (Typ.) |
| iarratas | DMPC |
