| Uimhir Pháirt | LTL070NL01-002 |
| Branda | Samsung |
| Méid | 7.0 |
| Iarratas | PAD |
| Rún | 1024×600 |
| Comhdhéanamh | LCM |
| Gile | 400 |
| CR | 800:1 |
| Dathanna | 16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | SAMSUNG |
| múnla painéil | LTL070NL01-002 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 7.0 inch |
| taifeach | 1024(RGB)×600 , WSVGA |
| mód taispeána | PLS, Normally Black, Transmissive |
| limistéar gníomhach | 153.6×90 mm |
| imlíne | 164.05×99.96×4.37 mm |
| dromchla | Glare (Haze 0%), Hard coating (3H) |
| gile | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) |
| dathanna a thaispeáint | 16.2M (6-bit + FRC), CIE193150% |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 6S4PWLEDEmbedded (LED Driver) |
| comhéadan comhartha | LVDS (1 ch, 8-bit), 31 pins |
| voltas ionchuir | 3.7V (Typ.) |
| iarratas | PAD |
