| Uimhir Pháirt | LSC480HN10 |
| Branda | SAMSUNG |
| Méid | 48 |
| Iarratas | TV Sets |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD, CELL |
| Gile | |
| CR | 4000:1 |
| Dathanna | 1.07B |
| Cúlsolas | No |
| Comhéadan | LVDS |
| branda | SAMSUNG |
| Mionsamhail | LSC480HN10 |
| méid trasnánach | 48 inch |
| cineál | a-Si TFT-LCD, CELL |
| formáid picteilín | 1920×1080(RGB) [FHD] 46PPI |
| cumraíocht | RGB Horizontal Stripe |
| limistéar gníomhach | 1054.08(H)×592.92(V) mm |
| imlíne dim. | 1068.08(H)×608.92(V) ×1.4(D) mm |
| limistéar bezel | - |
| cóireáil | Antiglare, Hard coating (2H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 4000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 8 (Typ.)(G to G) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| modh oibriúcháin | SVA, Normally Black, Transmissive |
| tiús pláta | 0.50+0.50 mm |
| tarchur | 6.6% (Typ.)(with Polarizer) |
| dath tacaíochta | 1.07B 68% NTSC |
| foinse solais | No B/L |
| meáchan | 1.90Kgs (Typ.) |
| deartha le haghaidh | TV Sets |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| sonraí d-ic | COF Built-in 2 source chips |
| cineál comhéadan | LVDS (2 ch, 10-bit) , 51 pins Connector |
| soláthar leictreachas | 12.0V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
