| Uimhir Pháirt | LSC480HN08-W |
| Branda | SAMSUNG |
| Méid | 48 |
| Iarratas | TV Sets |
| Rún | 1920×1080 |
| Comhdhéanamh | CELL, a-Si TFT-LCD |
| Gile | |
| CR | 5000:1 |
| Dathanna | 1.07B |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | SAMSUNG |
| ainm samhail | LSC480HN08-W |
| méid scáileáin | 48 inch |
| cineál scáileáin | CELL, a-Si TFT-LCD |
| uimhir picteilín | 1920×1080(RGB) (FHD) 46PPI |
| socrú | RGB Horizontal Stripe |
| limistéar gníomhach(mm) | 1054.08 × 592.92 (H×V) |
| imlíne (mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare (Haze 2.3%), Hard coating (2H) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 5000 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 8 (Typ.)(G to G) ms |
| radharc maith ag | Symmetry |
| modh oibre | SVA, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | 6.6% (Typ.)(with Polarizer) |
| doimhneacht dath | 1.07B 68% NTSC |
| cúlsolas | No B/L |
| mais | 1.90Kgs (Typ.) |
| a úsáidtear le haghaidh | TV Sets |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Ic liosta tiománaí | Built-in COF 3 source chips |
| cineál comhartha | LVDS (2 ch, 10-bit) , Connector 51 pins |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
