| Uimhir Pháirt | LSC320AN09-H |
| Branda | SAMSUNG |
| Méid | 32.0 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | a-Si TFT-LCD , CELL |
| Gile | |
| CR | 4000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| branda painéil | SAMSUNG |
| méid an phainéil | 32.0" |
| taifeach | 1366×768(RGB), WXGA, 49PPI |
| limistéar taispeána | 697.685(W)×392.256(H) mm |
| méid imlíne | 713(W)×410.5(H) ×1.3(D) mm |
| gile | 0 cd/m² |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| doimhneacht gloine | 0.50+0.50 mm |
| dathanna a thaispeáint | 16.7M 69% NTSC |
| minicíocht | 60Hz |
| Tiománaí ic | COF Built-in 1 source chips |
| meáchan painéal | 800g (Typ.) |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltas ionchuir | 12.0V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
| múnla painéil | LSC320AN09-H |
| cineál painéil | a-Si TFT-LCD , CELL |
| formáid picteilín | RGB Horizontal Stripe |
| oscailt bezel | - |
| dromchla | Antiglare (Haze 2%), Hard coating (2H) |
| cóimheas codarsnachta | 4000:1 (Typ.) (TM) |
| mód taispeána | SVA, Normally Black, Transmissive |
| am freagartha | 20 (Typ.)(G to G) |
| transmissivity | 6.9% (Typ.)(with Polarizer) |
| cineál lampa | No B/L |
| scáileán tadhaill | Without |
| iarratas | TV Sets |
