| Uimhir Pháirt | LQ800D3HA01 |
| Branda | Sharp |
| Méid | 80 |
| Iarratas | TV Sets |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD, CELL |
| Gile | |
| CR | 5000:1 |
| Dathanna | 1.07B |
| Cúlsolas | No |
| Comhéadan | LVDS |
| branda painéil | Sharp |
| múnla painéil | LQ800D3HA01 |
| méid an phainéil | 80" |
| cineál painéil | a-Si TFT-LCD, CELL |
| taifeach | 1920(RGB)×1080, FHD, 27PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 1771.2(W)×996.3(H) mm |
| oscailt bezel | - |
| méid imlíne | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| dromchla | Antiglare (Haze 3%), Hard coating (2H) |
| gile | 0 cd/m² |
| cóimheas codarsnachta | 5000:1 (Typ.) (TM) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| mód taispeána | ASV, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 4 (Typ.)(G to G) |
| doimhneacht gloine | - |
| transmissivity | 6.51% (Typ.)(with Polarizer) |
| dathanna a thaispeáint | 1.07B 73% NTSC |
| cineál lampa | No B/L |
| minicíocht | 120Hz |
| scáileán tadhaill | Without |
| Tiománaí ic | COF Built-in 16 source + 10 gate chips |
| meáchan painéal | 7.80g (Typ.) |
| iarratas | TV Sets |
| comhéadan comhartha | LVDS (4 ch, 10-bit) , 92 pins Connector |
| voltas ionchuir | 12.0V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
