| Uimhir Pháirt | LQ092B5DW02 |
| Branda | SHARP |
| Méid | 9.2 |
| Iarratas | IA |
| Rún | 960×160 |
| Comhdhéanamh | LCM |
| Gile | 1050 |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | SHARP |
| múnla painéil | LQ092B5DW02 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 9.2 inch |
| taifeach | 960(RGB)×160 |
| mód taispeána | ASV, Normally Black, Transmissive |
| limistéar gníomhach | 230.4×38.4 mm |
| imlíne | 242×52.83×10.8 mm |
| dromchla | Antiglare |
| gile | 1050 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit) |
| am freagartha | 8/6 (Typ.)(Tr/Td) |
| uillinn féachana | |
| minicíocht | 60Hz |
| cineál lampa | 6S4PWLEDWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltas ionchuir | 3.3/13.4/25.0/-8.0V (Typ.)(VSHD/VSHA/VGH/VGL) |
| iarratas | IA |
