| Uimhir Pháirt | LQ084V1DG21 |
| Branda | SHARP |
| Méid | 8.4 |
| Iarratas | IA |
| Rún | 640×480 |
| Comhdhéanamh | LCM |
| Gile | 300 |
| CR | 250:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | TTL |
| branda painéil | SHARP |
| múnla painéil | LQ084V1DG21 1 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 8.4 inch |
| taifeach | 640(RGB)×480 , VGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 170.88×129.6 mm |
| imlíne | 216×152.4 mm |
| dromchla | Antiglare (Haze 28%), Hard coating (3H), Antireflection |
| gile | 300 cd/m² (Typ.) |
| cóimheas codarsnachta | 250:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit) |
| am freagartha | 20/40 (Typ.)(Tr/Td) |
| uillinn féachana | 55/55/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 31 pins |
| voltas ionchuir | 3.3/5.0V (Typ.)(VCC) |
| iarratas | IA |
