| Uimhir Pháirt | LQ070Y5DG01 |
| Branda | SHARP |
| Méid | 7.0 |
| Iarratas | CNS |
| Rún | 800×480 |
| Comhdhéanamh | LCM |
| Gile | 530 |
| CR | 250:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | TTL |
| branda painéil | SHARP |
| múnla painéil | LQ070Y5DG01 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 7.0 inch |
| taifeach | 800(RGB)×480 , WVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 152.4×91.44 mm |
| imlíne | 172.2×110.5×25 mm |
| dromchla | Antiglare, Antireflection |
| gile | 530 cd/m² (Typ.) |
| cóimheas codarsnachta | 250:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit) |
| am freagartha | 10/20 (Typ.)(Tr/Td) |
| uillinn féachana | 60/60/35/50 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 2 pcsCCFLWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltas ionchuir | 5.3/3.3/13.0/-11.7/-13.7/-17.0V (Typ.)(VLS/VSH/VDD/VEE/VCC/VSS) |
| iarratas | CNS |
