| Uimhir Pháirt | LQ050A5AG03 |
| Branda | Sharp |
| Méid | 5.0 |
| Iarratas | Automotive Display |
| Rún | 320×234 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 60:1 |
| Dathanna | Full |
| Cúlsolas | 1 |
| Comhéadan | Analog |
| monaróir | Sharp |
| ainm samhail | LQ050A5AG03 |
| méid scáileáin | 5.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 320(RGB)×234 79PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 102.124 × 74.763 (H×V) |
| imlíne (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antireflection |
| luminance | 320 cd/m² (Typ.) |
| cóimheas codarsnachta | 60 : 1 (Typ.) (TM) |
| uillinn féachana | 65/65/40/65 (Typ.)(CR≥5) |
| freagra | 30/50 (Typ.)(Tr/Td) ms |
| radharc maith ag | - |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | Full color |
| cúlsolas | 1 pcs CCFL , 10K hours , No Driver |
| mais | 180g (Max.) |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | - |
| scáileán tadhaill | Without |
| cineál comhartha | Analog RGB , Connector 22 pins |
| soláthar voltais | 8.0/-5.0V (Typ.)(VSH/VSL) |
| uas. rátálacha | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
