| Uimhir Pháirt | LP171WU1-TLA5 |
| Branda | LG Display |
| Méid | 17.1 |
| Iarratas | NBPC |
| Rún | 1920×1200 |
| Comhdhéanamh | LCM |
| Gile | 260 |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | LG.Philips LCD |
| múnla painéil | LP171WU1-TLA5 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 17.1 inch |
| taifeach | 1920(RGB)×1200 , WUXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 367.2×229.5 mm |
| imlíne | 382.7×267.2×7 mm |
| stíl cruth | Wedge (PCBA Bent, Depth ≥5.2mm) |
| dromchla | Glare (Haze 0%), Hard coating (4H) |
| gile | 260 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193150% |
| am freagartha | 16 (Typ.)(Tr+Td); 8 (Typ.)(G to G) |
| uillinn féachana | 65/65/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 6-bit), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
