| Uimhir Pháirt | LM230WF9-SSA3 |
| Branda | LG Display |
| Méid | 23.0 |
| Iarratas | Desktop Monitor |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 14S4P |
| Comhéadan | LVDS |
| branda painéil | LG Display |
| méid an phainéil | 23.0" |
| taifeach | 1920(RGB)×1080, FHD, 95PPI |
| limistéar taispeána | 509.184(W)×286.416(H) mm |
| méid imlíne | 517.2(W)×302.8(H) ×12.7(D) mm |
| gile | 250 cd/m² (Typ.) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 72% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 1.79/1.88Kgs (Typ./Max.) |
| comhéadan comhartha | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltas ionchuir | 5.0V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| múnla painéil | LM230WF9-SSA3 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Antiglare (Haze 25%), Hard coating (3H) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | IPS, Normally Black, Transmissive |
| am freagartha | 14 (Typ.)(G to G) |
| cineál lampa | 14S4P WLED , 30K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Desktop Monitor |
