| Uimhir Pháirt | LM140GF1L02 |
| Branda | PANDA |
| Méid | 14.0 |
| Iarratas | Laptop |
| Rún | 2560×1600 |
| Comhdhéanamh | LCM , Oxide TFT-LC |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| monaróir | PANDA |
| méid scáileáin | 14.0 inch |
| uimhir picteilín | 2560(RGB)×1600 (WQXGA) 215PPI |
| limistéar gníomhach(mm) | 301.824 × 188.64 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 300 cd/m² (Typ.) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 71% NTSC |
| cruth imlíne | Slim (PCBA Flat, T≤3.2mm) |
| ráta athnuachana | 60Hz |
| cineál comhartha | eDP (2 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 30 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | LM140GF1L02 (NCP006A) 1 Compatible |
| cineál scáileáin | LCM , Oxide TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 306.824 × 205.84 × 2.4 (H×V×D) |
| cóireáil | Antiglare (Haze 25%) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| modh oibre | FFS, Normally Black, Transmissive |
| cúlsolas | WLED , 15K hours , With LED Driver |
| a úsáidtear le haghaidh | Laptop |
| scáileán tadhaill | Without |
| B140XTN03.2 | AUO | 14.0 | 1366×768 |
| B140XTN03.5 | AUO | 14.0 | 1366×768 |
| BT140GW01 V.A | Innolux | 14.0 | 1366×768 |
| CLAA140WB01A | CPT | 14.0 | 1366×768 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| HSD140PNW1-B00 | HannStar | 14.0 | 1600×900 |
| LP140WH1-TLC3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP140WH6-TJA1 | LG Display | 14.0 | 1366×768 |
| N140B6-D11 | Innolux | 14.0 | 1366×768 |
