| Uimhir Pháirt | LA123WF4-SR05 |
| Branda | LG Display |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 8S6P |
| Comhéadan | RSDS |
| branda painéil | LG Display |
| múnla painéil | LA123WF4-SR05 |
| méid an phainéil | 12.3" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1920(RGB)×720, 167PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 292.032(W)×109.512(H) mm |
| oscailt bezel | 296.03(W)×113.5(H) mm |
| méid imlíne | 310(W)×128(H) ×10.75(D) mm |
| dromchla | Hard coating |
| gile | 420 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Min.) (TM) |
| uillinn féachana | 89/89/89/89 (Min.)(CR≥10) |
| mód taispeána | IPS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| dathanna a thaispeáint | 16.7M 77% NTSC |
| cineál lampa | 8S6P WLED , 10K hours , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 395/405g (Typ./Max.) |
| iarratas | Automotive Display |
| comhéadan comhartha | RSDS (2 Channel) , 110 pins FPC |
| voltas ionchuir | 3.3/13.0V (Typ.)(VCC/VDD) |
| timpeallacht | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
