| Uimhir Pháirt | LA123WF4-SR03 |
| Branda | LG Display |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | RSDS |
| branda | LG Display |
| Mionsamhail | LA123WF4-SR03 |
| méid trasnánach | 12.3 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1920(RGB)×720 167PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 292.032(H)×109.512(V) mm |
| imlíne dim. | 310(H)×128(V) ×10.75(D) mm |
| limistéar bezel | 296.03(H)×113.5(V) mm |
| cóireáil | Hard coating |
| luminance | 600 cd/m² (Min.) |
| cóimheas codarsnachta | 800:1 (Min.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| uillinn féachana | 89/89/89/89 (Min.)(CR≥10) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 77% NTSC |
| foinse solais | WLED [11S4P] , 10K hours , W/O Driver |
| meáchan | 385/400g (Typ./Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | RSDS (2 Channel) , 110 pins FPC |
| soláthar leictreachas | 3.3/13.0V (Typ.)(VCC/VDD) |
| timpeallacht | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
