| Uimhir Pháirt | LA123WF1-SR02 |
| Branda | LG Display |
| Méid | 12.3 |
| Iarratas | Automotive Display |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | RSDS |
| branda | LG Display |
| méid trasnánach | 12.3 inch |
| formáid picteilín | 1920(RGB)×720 167PPI |
| limistéar gníomhach | 292.032(H)×109.512(V) mm |
| limistéar bezel | - |
| luminance | 600 cd/m² (Min.) |
| treo amharc | Symmetry |
| uillinn féachana | 89/89/89/89 (Min.)(CR≥10) |
| dath tacaíochta | 16.7M 86% NTSC |
| meáchan | 390/405g (Typ./Max.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | RSDS (2 Channel) , 110 pins FPC |
| soláthar leictreachas | 3.3/13.0V (Typ.)(VCC/VDD) |
| timpeallacht | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| Mionsamhail | LA123WF1-SR02 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 310(H)×128(V) ×11.05(D) mm |
| cóireáil | Antiglare, Antireflection |
| cóimheas codarsnachta | 800:1 (Min.) (TM) |
| am freagartha | 30 (Typ.)(Tr+Td) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| foinse solais | WLED [8S6P] , 10K hours , W/O Driver |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | Without |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
