| Uimhir Pháirt | LA102WH2-SL01 |
| Branda | LG Display |
| Méid | 10.2 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 10S4P |
| Comhéadan | LVDS |
| monaróir | LG Display |
| ainm samhail | LA102WH2-SL01 |
| méid scáileáin | 10.2 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1280(RGB)×720 (WXGA) 143PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 225.792 × 127.008 (H×V) |
| imlíne (mm) | 238.62 × 141.5 (H×V×D) |
| limistéar bezel (mm) | 225.75 × 126.874 (H×V) |
| cóireáil | Hard coating (3H) |
| luminance | 725 cd/m² (Min.) |
| cóimheas codarsnachta | 800 : 1 (Min.) (TM) |
| uillinn féachana | 89/89/89/89 (Min.)(CR≥10) |
| freagra | 30 (Max.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M |
| cúlsolas | 10S4P WLED , 10K hours , No Driver |
| mais | 303/313g (Typ./Max.) |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 8-bit) , FPC 64 pins |
| soláthar voltais | 1.8/3.3/12.5/18.5/-7.5V (Typ.)(DVDD2/DVDD1/AVDD/VHG/VHL) |
| uas. rátálacha | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.16G (31.0 m/s²) |
