| Uimhir Pháirt | LA084X02-SL01 |
| Branda | LG Display |
| Méid | 8.4 |
| Iarratas | Automotive Display |
| Rún | 1024×768 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.2M |
| Cúlsolas | 10S3P |
| Comhéadan | LVDS |
| monaróir | LG Display |
| ainm samhail | LA084X02-SL01 |
| méid scáileáin | 8.4 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×768 (XGA) 152PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 170.496 × 127.872 (H×V) |
| imlíne (mm) | 184.5 × 143 × 9.95 (H×V×D) |
| luminance | 1200 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Min.)(CR≥10) |
| freagra | 40 (Max.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.2M 70% NTSC |
| cúlsolas | 10S3P WLED , No Driver |
| mais | 255/260g (Typ./Max.) |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 8-bit) , FPC 40 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.84G (27.8 m/s²) |
