| Uimhir Pháirt | LA070WV7-SL02 |
| Branda | LG Display |
| Méid | 7.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1100:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S3P |
| Comhéadan | LVDS |
| monaróir | LG Display |
| ainm samhail | LA070WV7-SL02 |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| imlíne (mm) | 166.4 × 106.2 × 10.7 (H×V×D) |
| limistéar bezel (mm) | 158.4 × 94.2 (H×V) |
| cóireáil | Antiglare (Haze 25%) |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 1100 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 16/14 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 65% NTSC |
| cúlsolas | 6S3P WLED , 30K hours , No Driver |
| mais | 162/167g (Typ./Max.) |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 8-bit) , FPC 50 pins |
| soláthar voltais | 3.3/13/18/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| uas. rátálacha | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
