| Uimhir Pháirt | HV550QUB-N8D |
| Branda | BOE |
| Méid | 55 |
| Iarratas | TV Sets |
| Rún | 3840×2160 |
| Comhdhéanamh | CELL , a-Si TFT-LC |
| Gile | |
| CR | 1200:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | V-by-One |
| monaróir | BOE |
| méid scáileáin | 55 inch |
| uimhir picteilín | 3840(RGB)×2160 (UHD) 80PPI |
| limistéar gníomhach(mm) | 1209.6 × 680.4 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 0 cd/m² |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| tiús gloine | 0.50+0.50 mm |
| doimhneacht dath | 16.7M 76% NTSC |
| mais | 2.70Kgs (Typ.) |
| ráta athnuachana | 60Hz |
| Ic liosta tiománaí | Built-in COF 12 source chips |
| cineál comhartha | V-by-One 8 lane , 51 pins Connector |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | HV550QUB-N8D |
| cineál scáileáin | CELL , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 1221.4 × 694.8 × 1.34 (H×V×D) |
| cóireáil | Antiglare (Haze 1%), Hard coating (2H) |
| cóimheas codarsnachta | 1200 : 1 (Typ.) (TM) |
| freagra | 8 (Typ.)(G to G) ms |
| modh oibre | ADS, Normally Black, Transmissive |
| transmissivity | 5.3% (Typ.)(with Polarizer) |
| cúlsolas | No B/L |
| a úsáidtear le haghaidh | TV Sets |
| scáileán tadhaill | Without |
